BlueCrest | TrueSort Advanced Parcel Sorter

Scaleable

Widest material spectrum available in the industry.

Flexible

Linear cross-belt technology and standard design options provide flexibility to the client.

Tailored

Tailor your system for sorting into bags, carts, or sliding chutes.

TrueSort parcel sorting chutes with poly bags. padded envelopes, and boxes

Automated parcel with TrueSort sorting chutes

Large scale BlueCrest TrueSort application

TILT
Design throughput:	6-12k trays per hour
Induction:	Manual placement on trays
Barcode/OCR/Image capture options:	Inline on the transport, top-facing
Weight & dimension capture:	Offline encoding desks
Product mix:	Sorts full product mix including irregular small items
Maximum dimensions (LxWxD):	13 in. x 13 in. x 10 in. (US)	330mm x 330mm x 250mm
Minimum dimensions (LxWxD):	None
Product weight:	2, 3 or 4 Tiers 0.22 - 10lbs (US)	1 tier 0.1 - 12kg (UK)
Layout options:	Linear or loop configuration
Sort to:	Sacks, carts, gaylords
PUSH
Design throughput:	5-10k trays per hour
Induction:	Manual placement on trays
Barcode/OCR/Image capture options:	Inline on the transport, top-facing
Weight & dimension capture:	Offline encoding desks
Product mix:	Sorts full product mix including irregular small items. Gentle transfer of fragile items.
Maximum dimensions (LxWxD):	40 in. x 28 in. x 20 in. (US)	1000mm x 700mm x 500mm
Minimum dimensions (LxWxD):	None
Product weight:	0.22 - 53lbs (dual tray) \| 0.22 - 26lbs (single tray) (US)	0.1 - 24kg (dual tray) \| 0.1 - 12kg (single tray) (UK)
Layout options:	Loop configuration
Sort to:	Sacks, carts, gaylords
BOMB BAY
Design throughput:	6-14k trays per hour
Induction:	Manual placement on trays
Barcode/OCR/Image capture options:	Inline on the transport, top-facing
Weight & dimension capture:	Offline encoding desks
Product mix:	Sorts full product mix including irregular small items. Exit drop limits used for fragile items
Maximum dimensions (LxWxD):	43 in. x 25 in. x 12 in. (US)	1100mm x 650mm x 300mm
Minimum dimensions (LxWxD):	4 in. x 4 in. x 0.5 in. (US)	102mm x 102mm x 7mm (UK)
Product weight:	0.22 - 22lbs (US)	0.1 - 10kg (UK)
Layout options:	Loop configuration
Sort to:	Sacks, carts, gaylords
SHOE
Design throughput:	2-5k trays per hour
Induction:	Automated induction lanes
Barcode/OCR/Image capture options:	Inline on the transport, up to 5 sides
Weight & dimension capture:	Inline on the transport
Product mix:	Sorts large and heavy packages. Not ideal for regular and small items
Maximum dimensions (LxWxD):	59 in. x 35 in. x 35 in. (US)	1500mm x 900mm x 900mm
Minimum dimensions (LxWxD):	4 in. x 4 in. x 0.5 in. (US)	102mm x 102mm x 7mm (UK)
Product weight:	0.22 - 110lbs (US)	0.1 - 50kg (UK)
Layout options:	Linear configuration
Sort to:	Gravity feed, controlled descent

TrueSort^® Advanced
Automated High-Speed Parcel Sorter

Parcel Sorter Built with Flexible Linear Cross-Belt Technology.

An automated conveyor and sortation system that meets the needs of any parcel sorting application.

Scaleable

Flexible

Tailored

Customizable Options

OCR Address Reading

Product Specifications
